Fast Protec Support

Working on magnetic condyles, the Fast Protec Articulator perfectly simulates protrusive and lateral occlusion movements. This articulator will allow you maximum visibility thanks to its posterior incisal guide pin and the possibility to set the model on it just using the Fast Clean Base and silicone instead of plaster.

Combined Verticulator and Articulator in one unit just changing the lid. A flexible instrument to enable different processing in record time. Thanks to its posterior incisal guide pin and its magnetic condyles, Verarte allows you a 360° visibility and a perfect simulation of the natural mouth movements.

Verticulator and Flask All-In one. The three-axis Verticulator enables different processing as dentures, implant dentures, and ceramic molding, facilitating the work and allowing you a wide visibility. It is extremely useful for visualizing the case and to ease the casework planning. Simply by placing the Flask lid through magnetic attachment to the lid of the Verticulator, you will be able to finalize a full denture either through the injection or the pouring technique.

Step by Step Instructions

Easy bar is a kit of preformed bars that facilitate the realization of a stable, precise and reinforced structure for all kind of fixed dental prosthetics in just 6 hours. Thanks to their different sizes (from 6 to 30 mm), these bars could be adapted by bending to any position of the implants and are compatible to every implant abutment on the market. Available in stainless steel or titanium.

• 245 Preformed bars made of stainless steel
• Available in 49 different sizes (from 6mm up to 30 mm considering center to center distance)
• 1.5 mm thickness
• They can be adapted by bending to the different positions of the implants

01. Implant denture model

02. Control of the bar position (previously fixed in mouth)

03. Model set on Articulator

04. Easy Bar structure welded

05. Easy Bar structure cemented on the abutments

06. Mounting of the teeth

07. Silicone templates

08. Opacified structure

09. Teeth insertion

10. Injection of the resin

11. Final result

Add sprue formers for access holes.

Enclose the model in the Alu-Big.

Mold Precision Blue onto model with out leaving any gaps or cracks in between silicone and model.

After molding /Fast Putty over Fast Precision Blue, insert top flask over Fast Putty for a sealed tight fit. Wait for 5 minutes.

Remove sprue pins.

Using a brush apply acrylic onto teeth for maximum bond.

Pour acrylic into access hole slowly until it pours out second hole.

Cut sprues and polish.

Duplicate Flask for Temporaries

Implant box is a flask with a minimal and compact design that allows you to cast the model in plaster directly on the base. Thanks to the integrated split cast it is possible to perfectly fit the base on Fast Protec Articulator, Verarte and All-In. It is provided with two tips: the metallic one is useful to perform crown and bridges and implant dentures whereas the clear one is perfect to work with light-curing composites.

Big and Small Glass

Its compact shape, makes the Small Glass the ideal flask to realize works from 1 to 6 elements. Thanks to its additional lid, this flask allows technicians to perform implant dentures, joining the advantages of the Small Glass with those of the Light Glass, reducing any waste of Silicone and working on teeth and gingiva.

Light Glass

Wider than traditional transparent flasks and more stable with its three screws, Light Glass allows dental technicians to perform full implant dentures working simultaneously on composite teeth and gingiva thanks to the provided three lids and the removable three pins. Its completely clear structure guarantees a fast and total light-curing of the elements obtaining perfect and precise details.

Light Box

New Light Box is a compact and modern polymerization unit provided with last generation multi-die LEDs for light-curing composite resins. A low consumption machine that works on a vacuum pump to avoid the dispersion layer, the New Light Box is perfect to light-cure the Fast Protec wide range of composites at a wave frequency between 360 and 520 nm.
