BREDENT RESIN SUPPORT
Exakto-Form Resin
INSTRUCTIONS FOR USE EXAKTO-FORM MODEL RESIN
Dual component model material, based on polyurethane, for fabricating extremely precise dental models. Thanks to its very low viscosity, it is easily poured into impressions without entrapping air voids. This cost-effective model resin features absolutely precise reproduction of surfaces, dimensional stability and unequaled precision of fit with no expansion whatsoever.
- Presentation
- - Exakto-form model resin is supplied in cans containing 50 g. each of components A and B.
- - 1 assortment includes 6 x 50 g. cans components A and 6 x 50 g. cans of component B.
- - Both components are also available separately.
Directions - Application I
Always follow safety precautions!
Shake the tubs well before opening. Rip the lids off both tubs. To ensure that components A and B are mixed homogeneously, they must be stirred thoroughly before using, to mix the material which has settled.
Pour the contents of the component B tub into the tub containing component A (mixing ratio 1:1). Mix the two components thoroughly within 30 seconds. Working time is 2 to 3 minutes. Separate from impression after 30 minutes; maximum final hardness is achieved after 1.5 hours.
Application I
As this is a polyurethane based, dual-component material, it is inevitable that component B will react prematurely with the mixture in the atmosphere when the can is opened. Therefore, to prevent the moisture in the atmosphere from contacting the material for too long, and consequent premature setting, component B should be used immediately!
Directions - Application II
Should you require a small amount of Exakto-Form model resin (less than 100 g), you can fill the entire contents of tubs A & B into separate syringes and extrude the desired amount into a mixing vessel in a ratio of 1:1. Mix the two components thoroughly within 30 seconds. Working time 2-3 minutes. Separate from impression after 30 minutes. Maximum final hardness attained after 1.5 hours. Please make absolutely certain that you use the remaining material in the syringes within 2 days! Shake the tubs well before opening. Rip the lids off both cans. To ensure that components A & B are mixed homogeneously, they must be stirred thoroughly before each use to mix material which may have settled.
Application II
- Safety Measures
- " Wear protective clothing, gloves, and glasses/face mask.
- " In case of contact with the skin, wash immediately with plenty of soap and water.
- " In case of contact with the eyes, rinse immediately with plenty of soap and water and seek medical attention immediately.
- " Do not inhale vapors - use in well ventilated areas.
- " In case of an accident or sudden indisposition, seek medical attention immediately (if possible, show package label).
- " Keep out of reach of children.
- " Keep out of sewage system, inshore waters, and earth.
- " Keep away from open fire.
- " GGVE/S 6 1 code 19 c.
The general industrial hygiene precautions applying to reactive resins and their hardeners should be followed.
MATERIAL SAFETY DATA SHEET
Product Name: EXAKTO FORM MODEL RESIN COMPONENT A - RESIN
Product Code: 520 001 74, 520 002 80
Before using this product, please read and follow these instructions carefully.
1. Composition/Information on ingredients
Product Description/use: Pigments in a mixture of solvents and polyols.
Hazardous Substances:
Name: CAS-No. Content Hazard symbols Hazard codes
White Spirit --- --- --- R 10
2. Hazard Identification
Hazard codes R 10 flammable.
3. First aid procedures:
Inhalation: Plenty of fresh air and in case of complications seek medical assistance.
Skin contact: Wash skin with soap and rinse with plenty of water; in case of irritation seek medical attention.
Eye contact: Flush immediately with pure water for at least 15 minutes; seek medical attention.
Ingestion: Do not induce vomiting, and seek immediate medical attention.
Others: Remove soaked clothing immediately.
4. Fire fighting procedures:
Suitable extinguishing media: Water-spray, CO2, dry chemicals, foam.
Unsuitable extinguishing media: High-pressure water jet.
Exposure hazards: Thermal decomposition can lead to the generation of irritant vapor and/or fire.
Special equipment: Pressure demand self-contained breathing apparatus should be provided to fire fighters in buildings.
5. Accidental release procedures:
Precautions - individuals: Wear protective equipment; avoid contact with eyes and skin. Do not breathe vapor; always use in a well-ventilated area.
Precautions - environment: Stop leaks as soon as possible and avoid discharge into environment.
Cleaning up spillage: Absorb with mineral fillers (such as sand, diatomaceous earth,) and store in a well-sealed, suitable container.
6. Storage and handling:
Storage: Store in a well-sealed container in a well-ventilated room. Do not expose to temperatures exceeding 30º C; store away from food.
Handling: Avoid contact with eyes or skin; always use in a well-ventilated area; do not breathe vapor. Do not smoke. Keep away from sources of ignition.
7. Exposure control/individual protection
Individual:
Protection-hands: Protective gloves..
Protection-eyes: Protective glasses.
Protection-skin: Working coat (cotton).
General procedures with respect to individual hygiene: Avoid inhalation; avoid eye and skin contact. Do not eat, drink or smoke while.
working. After working, wash your hands with soap and water.
8. Physical and chemical properties:
Appearance:Liquid.
Color: Opaque, greenish.
Odor: Typical.
Data relevant to safety:
Acidity (pH): 10
Flash point: 42º C.
Ignition point: 420º C.
Self-inflammation: None.
Vapor pressure (20º C): 7-8 mbar.
9. Stability and reactivity:
Conditions to avoid: Do not expose to temperatures exceeding 50 C or below 5º C.
Materials to avoid: Avoid direct contact to strong oxidants or isocyanates.
Hazardous decomposition products: Thermal decomposition leads to the generation of irritant vapors.
10. Toxicological information:
Toxicological evaluation: The toxicological properties have not been fully determined.
Irritating properties: Direct contact with skin or eyes may cause irritation or reddening.
Sensitization: None have been reported yet.
Carcinogenic, teratogenic, or mutagenic effects: None have been reported yet.
11. Ecological information:
Avoid discharge into the environment.
12. Disposal consideration:
Product/Soiled container: Both need to be classified as chemical waste material and disposed of in agreement with your local and national legislation.
13. Export regulation
By land:
ADR/RID/GGVS/GGVE class: 3 No./Letter: 31.c)
Warning symbol: F Hazard No.: 30 Material No.: 1993
By air:
ICAO/IATA class: 3 UN/ID No.: 1993 Verp. Grp.: III/309
Correct technical name: White spirit.
14. Regulatory information:
Hazard symbol and identification: Flammable.
Hazard codes: R 10 Flammable.
Safety codes: S 16 Keep away from sources of ignition.
S 24/25 Avoid contact with eyes or skin.
15. Other information
Data sheet completed by: Research & Development Dept. - Bredent (Germany).
This Material Safety Data Sheet is provided by way of guide for the use of our product and is
correct to the best of our knowledge.
However, we can't offer any guarantee as to its accuracy or
exhaustiveness. All chemicals may present unforeseen risks and should be used with caution.
We cannot guarantee that the risks referred above are the only risks present. The final choice of the application of a
product is thus the sole responsibility of the user.
MATERIAL SAFETY DATA SHEET
Product Name: EXAKTO FORM MODEL RESIN COMPONENT B - HARDENER
Product Code: 520 001 73, 520 002 80
Before using this product, please read and follow these instructions carefully.
1. Composition/Information on ingredients
Product Description/use: Hardener of a two compound model resin.
Name: CAS-No. Content Hazard symbols Hazard codes.
Dyphenylmethane-4,4' 101-68-8 Xn R 20; 36/37/38; 42
Diisocyanate.
2. Hazard Identification
Hazard codes: R 20 Harmful by inhalation.
R 36/37/38 Irritating to eyes, respiratory system & skin.
R 42 Sensitization may be caused by inhalation.
3. First aid procedures:
Inhalation: Plenty of fresh air and in case of complications seek medical assistance.
Skin contact: Wash skin with soap and rinse with plenty of water; in case of irritation seek medical attention.
Eye contact: Flush immediately with pure water for at least 15 minutes; seek medical attention.
Ingestion: Do not induce vomiting, and seek immediate medical attention.
Others: Remove soaked clothing immediately.
4. Fire fighting procedures:
Suitable extinguishing media: Water spray, CO2, dry chemicals, foam.
Unsuitable extinguishing media: High-pressure water jet.
Exposure hazards: High temperatures lead to the generation of irritant vapor and/or fire.
5. Accidental release procedures:
Precautions - individuals: Wear protective equipment; avoid contact with eyes and skin. Do not breathe vapor; always use in a well-ventilated area.
Precautions - environment: Stop leaks as soon as possible and avoid discharge into environment.
Cleaning up spillage: Absorb with mineral fillers (such as sand, diatomaceous earth,) and store in a well-sealed suitable container.
6. Storage and handling:
Storage: Store in a well-sealed glass container in a dry, well-ventilated room. Store at temperatures between 18 and 22º C; store away from food.
Handling: Avoid contact with eyes or skin; always use in a well-ventilated area; do not breathe vapor. Do not smoke.
7. Exposure control/individual protection
Constituents with limits relevant to the work area:
CAS-No.: Description: Type Value Unit
101-68-8 Diphenylmethane-4,4'-diisocyanate MAK 0.05 ppm
Individual:
Protection-hands: Protective gloves.
Protection-eyes: Protective glasses are recommended.
Protection-skin: Working coat (cotton).
General procedures with respect to individual hygiene: Avoid inhalation; avoid eye and skin contact. Do not eat, drink or smoke while working. After working, wash your hands with soap and rinse with water thoroughly.
8. Physical and chemical properties:
8. Physical and chemical properties
Appearance: Opaque liquid.
Color: Yellowish.
Odor: Typical.
Data relevant to safety:
Flash point: > 100º C.
Ignition point: 240º C.
Self-inflammation: No.
Vapor pressures (20º C): 8 mbar.
Specific density (20 C): 1.76 g/ml.
9. Stability and reactivity:
Conditions to avoid: Avoid temperatures exceeding 30 C and below 18º C.
Materials to avoid: Avoid peroxides, amins, alcohols and water.
Hazardous decomposition products: Reaction with water in a sealed container may cause a rising pressure and leads to the explosive destruction of the container.
10. Toxicological information:
Toxicological evaluation:
Acute toxicity:
LD50/LC50: Substance Species Kind of exposure
15000 mg/kg Diphenylmethane- Rat Oral
4,4'-diisocyanate
Irritating properties: Irritates mucous membranes, eyes and skin.
Sensitization: May cause sensitization symptoms like asthma.
Carcinogenic, teratogenic, or mutagenic effects: None have been reported yet.
11. Ecological information:
Avoid discharge into the environment.
12. Disposal consideration:
Product: This product needs to be classified as chemical waste material and disposed of in agreement with your local and national legislation.
Soiled container: Empty the bottle entirely; then dispose of in agreement with your local and national legislation.
13. Export regulation
Transport: Non-regulated.
14. Regulatory information:
Hazard symbol & identification: Xi = Irritant; F = Highly Flammable.
Hazardous substances: Methyl methacrylate.
Hazard codes: R 11 Highly flammable.
R 36/37/38 Irritates eyes, respiratory organs, and skin.
R 43 Direct skin contact may cause sensitization.
Safety codes: S 9 Store in well ventilated rooms only.
S 16 Avoid direct contact with sources of ignition-do not smoke.
15. Other information
Data sheet completed by: Research & Development Dept. - Bredent (Germany).
This Material Safety Data Sheet is provided by way of guide for the use of our product and is
correct to the best of our knowledge.
However, we can't offer any guarantee as to its accuracy or
exhaustiveness. All chemicals may present unforeseen risks and should be used with caution.
We cannot guarantee that the risks referred above are the only risks present. The final choice of the application of a
product is thus the sole responsibility of the user.
1.Prior to mixing, each component must be stirred so that a homogeneous mixture is obtained. Mix the sediment completely.
2.Add component A to component B; empty tin completely.
3.Mix Exakto-Form approximately 30 seconds until a uniform color is obtained.
4.Two tins of Exakto-Form are sufficient to produce 2-3 complete dental arches.
5.The material can be removed after 30 minutes. Final hardness is achieved after 90 minutes. Then the model can be trimmed.
6.If a base for the model is to be produced with Exakto-Form, the model must first be insulated with Exakto-Form Insulating Liquid.
7.Due to its high edge stability, Exakto-form is perfectly suitable for precision-fit bridge and crown work.
8.Any technique can be used for sawing Exakto-Form models. Adopting a new technique is not required.
9.If smaller quantities are used, fill component A and B into separate syringes.
10.Pour equal quantities of Exakto-Form into a silicone beaker (approximately 2 ml for one die) and mix to obtain a homogeneous material. Please note, material in syringes must be used within 5 days.
11.Pour Exakto-Form into the impression. The excellent flow properties prevent the formation of bubbles even in impressions with thin edges.
12.The hardened resin can be drilled and trimmed. The stability avoids dimensional changes and guarantees precise models.
Pi-ku-plast HP 36
Pi-ku-plast HP 36 Precision Pattern Resin
Optimum contouring properties, will not slump. Available in 5 different transparent colors to allow the thickness to be checked and to contract well within the wax. When used with the Pi-Ku-Plast separating agent, resin inner copings can be base for producing milled restorations. Ideal for connecting bar sections for soldering.
Due to the multigrain design, Pi-Ku-Plast absorbs less monomer and therefore has less shrinkage. Various grain sizes shift into the gaps of each other for a compact, sturdy application. The burnout is clean and complete. In burnout, Pi-Ku-Plast does not expand but collapses. This puts no internal stress in the casting ring, resulting in a clean, stress-free casting.
Pikuplast Dip System
Control viscosity, Save material, Save time, Save money
Wet the brush with the Pi-Ku-Plast monomer. The amount and firmness of the portion can be controlled by the amount of monomer on the brush and the time it is immersed in the polymer. Because the material does not have to be pre-mixed, no resin is wasted due to over mixing the two components. After using, the brush is cleaned in the cleaner and the vessels are covered to keep the Pi-Ku-Plast in good working condition.
- Dip the flat side of the brush into the polymer to take up large portions.
- Dip the narrow side of the brush into the polymer to take up small portions.
- Dip only the brush tip into the polymer to take up very small portions.
Instructions
Optimal control of layer thickness thanks to the transparent colors of Pi-Ku-Plast HP36
Thanks to the smooth, high-lustrous reproduction of the metal surface of the primary element, a perfect inner surface of the secondary crown is obtained.
By using Pi-Ku-Plast Separating Agent, Order No. 540 001 82, for the first time ever, resin primary elements can be produced on varnish-coated dies. This is the perfect basis for milled restorations.
Entirely gap-free fit of the Pi-Ku-Plast outer coping allows perfect precision of the secondary elements.
Implant bars can be secured in place rigidly with optimal dimensional stability.
Pi-Ku-Plast HP 36
For accurate, stable and millable resin dies and frameworks
The competitor’s resin and Pi-Ku-Plast HP in the incineration test.
At 275°C the competitor’s product foams and expands considerably.
At 300°C the competitor’s product reveals distinctive expansion whereas Pi-Ku-Plast reduces in volume.
Identical copings produced with brush resin.
The competitor’s resin and Pi-Ku-Plast HP 36, prepared for investing.
The considerable expansion of the competitor’s resin during the incineration phase resulted in the fracture of the investment material die in the casting ring. After casting, the crown is sealed with a lid and cannot be used. A section through the cast crown shows the fractured die.
Through friction heat during grinding and high heat sensitivity, the plasticity phase of the competitor’s resin can be reached. Deformation of the model, rough grinding surfaces, and inadequate fit may result.
Pi-Ku-Plast features dimensional stability; during grinding fine shavings are obtained and a smooth grinding surface is ensured.
The considerable expansion of the competitor’s resin during the incineration phase resulted in the fracture of the investment material die in the casting ring. After casting, the crown is sealed with a lid and cannot be used. A section through the cast crown shows the fractured die.
The extremely low shrinkage of Pi-Ku-Plast allows to obtain a tension free model and precision fit casting.
INSTRUCTIONS FOR USE
PI-KU-PLAST
Before using this product, please read and follow these instructions carefully.
1. Indication Range
Pi-Ku-Plast is a cold-polymerizing resin for:
- modeling of secondary elements for all types of attachments and double crowns
- stress-free fixation and connection of crowns during soldering work and during the preparation of the wax pattern
- the production of resin dies
- copings on plaster dies; with the use of Pi-Ku-Plast separating agent (Item #540 001 82) as insulating agent.
2. Processing
2.1 Preparation of the object
The plaster dies must be insulated once with Pi-Ku-Plast separating agent before modeling the resin copings. Apply Pi-Ku-Plast after a drying time of approx. 5 min. The metal surfaces of primary elements should be polished to high luster and should not have undercuts in order not to render the removal of the Pi-Ku-Plast coping.
2.2 Preparation
Fill polymer, monomer and cleaner into the containers included in the Pi-Ku-Plast assortment. The color is included in the monomer. Put the enclosed round marking that corresponds to the color of the monomer into the monomer container.
Please note:
- Polymer and monomer must be poured back into the container. (Caution: cleaner must be removed from the brush before the brush is immersed into the monomer). It can be stored for a few days in well-sealed working containers.
- Do not mix cleaner with monomer. (Caution: the cleaner affects the accuracy of fit, resistance, to fracture and hardening).
- If polymer (powder) gets into the working container of the monomer (liquid), the liquid must be replaced. Otherwise the monomer polymerizes within 2 days - even in a well-sealed working container.
- After usage, the container must be immediately sealed again.
- Do not spill monomer - it stains!
2.3 Processing
Wet the brush with monomer and then dip the tip of the brush into the polymer. Depending on the monomer quantity on the brush, as well as the duration of immersion and the immersion depth in the polymer, the quantity that is absorbed can be varied. By keeping the resin on the tip of the brush for 2 - 5 seconds, a plastic modeling behavior is achieved so that even cusps and bulges can be easily applied. Accordingly, it is possible to take up the exact quantity of Pi-Ku-Plast required and to control the modeling behavior. Contamination of the monomer with polymer or also with the cleaner (wet brush after cleaning) can affect the properties of the resin (increased bonding to the metal, reduced hardness).
Recommendation: The monomer in the working container should be exchanged every day! Pi-Ku-Plast can be perfectly milled and does not form any gaps when it is applied onto Pi-Ku-Plast material that has already polymerized. Clean the brush before Pi-Ku-Plast has hardened.
Please note: After cleaning, the brush must be dried well; the cleaner must not get into the monomer!
2.4 Processing Time
The processing time varies depending on the room temperature. At 23º C it amounts to 4 - 5 min.
Further Processing
Pi-Ku-Plast can be applied in layers. The product can even be applied onto hardened Pi-Ku-Plast without the formation of fine gaps. It does not affect the quality of the pattern. All modeling waxes can be applied onto Pi-Ku-Plast.
Please note: Wax acts like an insulating material, therefore roughening of Pi-Ku-Plast is required before new application. Pi-Ku-Plast can be processed with all commercially available rotating instruments. If desired, Pi-Ku-Plast can also be polished. Pi-Ku-Plast is perfectly suitable for connecting wax patterns since it generates only minimum setting heat. During burning, Pi-Ku-Plast does not generate any expansion forces but it collapses. This way damage to the shape prior to the cristobalite crack is avoided.
2.5 Use in the patient
Pi-Ku-Plast is not an approved medical product and must not be used in the patient's mouth
3. Safety Recommendations and Hazard Warnings
3.1 Protective clothing
While working with Pi-Ku-Plast, safety glasses, protective clothing and safety gloves must be worn.
3.2 Pi-Ku-Plast must only be used in places that are well ventilated. Open fire/flame and smoking are prohibited.
3.3 For safe handling of Pi-Ku-Plast, please refer to the safety data sheet.
3.4 If Pi-Ku-Plast gets in contact with skin, mucous membrane or eyes, it must be immediately rinsed off with water. In case of allergic reactions, please seek medical attention.
4. Storage and Durability
4.1 Pi-Ku-Plast must be stored under dry conditions at a maximum temperature of 30º C and it must be protected from light. The durability can be increased by storing it in the refrigerator. If product is stored correctly, Pi-Ku-Plast has a shell life of approx. 18 months.
4.2 Monomer that has not been used must be poured back into the original storage container - risk of contamination!
Cleaner and monomer must be stored in separate containers. Mixing with cleaner results in irreversible damage to the monomer.
5. Further Information
The information contained in these instructions for use is always updated according to the latest knowledge and experience. Therefore, we recommend to read these instructions again before using a new package.
These instructions refer to Pi-Ku-Plast Item #s 540 001 73, 540 001 74, 540 001 75, 540 001 76, 540 001 77, and 540 001 82.
Product Name: PI-KU-PLAST POLYMER Product Code: 540 001 67
Before using this product, please read and follow these instructions carefully.
1. Composition/Information on ingredients
Product Description/use: Mixture of several polymethyl methacrylates.
Hazardous substances:
Name: CAS-No. Content Hazard symbol Hazard codes
Benzoyl-peroxide 94-36-0 / 1 - 5 % by w. / Xi R36, R43
2. Hazard Identification Xi Irritant.
Hazard codes R36 Irritant to eyes.
R43 May cause sensitization through skin contact.
3. First aid procedures
Inhalation: Plenty of fresh air, and in case of complications, seek medical assistance.
Skin contact: Wash with soap, rinse with plenty of water; in case of irritation seek medical assistance. Remove soaked clothing immediately.
Eye contact: Flush eyes immediately with pure water for at least 15 minutes; seek medical assistance.
Ingestion: Drink plenty of water; seek immediate medical attention.
4. Fire fighting procedures
Suitable extinguishing media: CO2, dry chemicals, water-spray, foam.
Unsuitable extinguishing media: High pressure water jet.
Exposure hazards: Thermal decomposition can lead to the generation of irritant vapor and gases and/or fire.
Special equipment: Pressure demand self-contained breathing apparatus should be provided to fire fighters in buildings.
5. Accidental release procedures
Precautions - individuals: Wear protective equipment; do not allow unprotected persons to enter the room.
Precautions - environment: Avoid discharge into the environment.
Cleaning up spillage: Collect and store in a well-sealed, suitable container.
6. Storage and handling
Storage: Store dry and in a well-sealed container. Avoid temperatures exceeding 30 C.
Handling: Avoid creating dust; avoid contact with eyes and skin; keep away from sources of ignition.
7. Exposure control/individual protection
Relevant to work area:
CAS-No.: Description: Type Value Unit
94-36-0 Benzoyl-peroxide MAK 5 mg/m3
Individual:
Protection-hands: Protective gloves.
Protection-eyes: Protective glasses are recommended.
Protection-skin: Working coat (cotton).
General procedures with respect to individual hygiene: Do not breathe dust, do not eat, drink or smoke while working; after working, wash your hands with soap and rinse with water.
8. Physical and chemical properties
Appearance:Solid.
Color: White.
Odor: Odorless.
Data relevant to safety:
Flash point: >250 C.
Ignition point: >400 C.
Self-inflammation: No.
Specify density: 1.11 g/cm3
Solubility in water (20 C; % by weight): Insoluble.
9. Stability and reactivity
Conditions to avoid: Avoid temperatures exceeding 40 C.
Materials to avoid: Avoid strong reductants.
Hazardous decomposition products: Thermal decomposition leads to the generation of gases; irritant to eyes and respiratory organs (methyl-methacrylate) and/or fire.
10. Toxicological information
Toxicological evaluation: The toxicological properties have not been fully determined.
Irritating properties: Benzoyl-peroxide may cause irritation to skin, eyes, and respiratory organs when in direct contact.
Sensitization: Sensitization, caused by benzoyl-peroxide, has been reported in several cases in literature.
Carcinogenic, teratogenic, or mutagenic effects: Benzoyl-peroxide is said to be carcinogenic.
11. Ecological information
Avoid discharge into the environment.
12. Disposal consideration
Product/Soiled Container: If in agreement with local and national regulations, dispose of product and container with house waste.
13. Regulatory information
Hazard symbols: Xi Irritant.
Hazardous substances: Benzoyl-Peroxide.
Hazard codes: R43 Direct skin contact may cause sensitization.
Safety codes: S36 Wear suitable protective gloves and glasses.
14. Other information
Data sheet completed by: Research & Development Dept. - Bredent (Germany).
This Material Safety Data Sheet is provided by way of guide for the use of our product and is correct to the best of our knowledge.
However, we can’t offer any guarantee as to its accuracy or exhaustiveness. All chemicals may present unforeseen risks and should be used with caution.
We cannot guarantee that the risks referred above are the only risks present. The final choice of the application of a product is thus the sole responsibility of the user.
Product Name: PI-KU-PLAST CLEANER
Product Code: 540 001 69
Before using this product, please read and follow these instructions carefully.
1. Composition/Information on ingredients
Product Description/use: Mixture of solvents.
Name: CAS-No.Content Hazard symbol Hazard codes
Ethyl acetate 141-78-6>50% by vol. F R 11
Isobutyl-acetate 110-19-0 < 50% by vol. F R 11
2. Hazard Identification F Highly flammable
Hazard codes R11 Highly flammable
3. First aid procedures
Inhalation: Plenty of fresh air, and in case of complications, seek medical assistance.
Skin contact: Wash with soap, rinse with plenty of water; in case of irritation seek medical assistance.
Eye contact: Flush immediately with pure water for at least 15 minutes; seek medical assistance.
Ingestion: Drink plenty of water; seek immediate medical attention.
Others: Remove soaked clothing immediately.
4. . Fire fighting procedures
Suitable extinguishing media: CO2, dry chemicals, water-spray, foam.
Unsuitable extinguishing media: High-pressure water jet.
Exposure hazards: Thermal decomposition can lead to the generation of irritant vapor and gases and/or fire.
Special equipment: Pressure demand self-contained breathing apparatus should be provided to fire fighters in buildings.
5. Accidental release procedures
Precautions - individuals: Wear protective equipment; do not allow unprotected persons to enter the room.
Precautions - environment: Stop leaks as soon as possible and avoid discharge into environment.
Cleaning up spillage: Absorb with mineral fillers (such as sand, diatomaceous earth) and store in a well-sealed suitable container.
6. Storage and handling
Storage: Store in a well-sealed glass container in a well-ventilated room. Do not expose to temperatures exceeding 40 C.
Handling: Take care for good ventilation for local or general exhaust, close container after use immediately.
7. Exposure control/individual protection
Relevant to work area:
CAS-No.: Description: Type Value Unit
141-78-6 Ethyl-acetate MAK 400 ppm
110-19-0 Isobutyl-acetateMAK 200 ppm
Individual:
Protection-hands: Protective gloves.
Protection-eyes: Protective glasses are recommended.
Protection-skin: Working coat (cotton).
General procedures with respect to individual hygiene: Avoid breathing the vapor, avoid eye and skin contact, do not eat, drink, or smoke while working; after working, wash your hands with soap and water; observe standard hygiene procedure.
8. Physical and chemical properties
Appearance: Clear liquid.
Color: No color.
Odor: Typical.
Data relevant to safety:
Melting point/interval: No data available.
Boiling point/interval: 76-78 C.
Flash point: -4 C.
Ignition point: 460 C.
Self-inflammation: No.
Lower explosion limit: 2.1% by vol. Upper explosion limit: 11.5% by vol.
Vapor pressure (20 C): 102 m bar.
Specify density: 0.899 - 0.901 g/ml.
Solubility in water (20 C; % by weight): Approx. 77 g/l.
9. Stability and reactivity
Conditions to avoid: Avoid temperatures exceeding 40 C; avoid contact with heat sources or sources of ignition.
Materials to avoid: Avoid direct contact with strong oxidants.
Hazardous decomposition products: Thermal decomposition leads to the generation of irritant vapor and/or fire.
10. Toxicological information
Toxicological evaluation: The toxicological properties have not been fully determined.
LD50/LC50: Substance Kind of exposure
13400 mg/kg Isobutyl-acetate Oral
11000 mg/kg Ethyl-acetate Oral
Irritating properties: Exposure to vapor for a long time leads to irritation of mucous membranes and may cause dizziness.
Sensitization: None have been reported yet.
Carcinogenic, teratogenic, or mutagenic effects: None have been reported yet.
11. Ecological information
Avoid discharge into the environment.
12. Disposal consideration
Product: The product has to be classified as chemical waste material and disposed of in agreement with local and national regulations.
Soiled container: Empty the bottle directly entirely and allow residues to evaporate in a well-ventilated area. Then dispose of the container in agreement with local and national regulations.
13. Regulatory information
Hazard symbols: F - highly flammable.
Hazardous substances: Ethyl-acetate, Isobutyl-acetate.
Hazard codes: R11 Highly flammable.
Safety codes: S 9 Store in well-ventilated rooms only.
S16 Avoid direct contact with sources of ignition - do not smoke.
S23 Do not breathe vapor.
S29 Avoid discharge into the environment or sewers.
S33 Take precautionary measures against static discharge.
14. Other information
Data sheet completed by: Research & Development Dept. - Bredent (Germany).
This Material Safety Data Sheet is provided by way of guide for the use of our product and is correct to the best of our knowledge.
However, we can’t offer any guarantee as to its accuracy or exhaustiveness. All chemicals may present unforeseen risks and should be used with caution.
We cannot guarantee that the risks referred above are the only risks present. The final choice of the application of a product is thus the sole responsibility of the user.
Qu-Resin
Qu-resin Features
Quick-setting, self-curing denture repair resin based on diacrylate for intraoral and extraoral (direct and indirect) use.
Qu-Resin is the perfect material when it comes to speed, regardless whether used in practices or laboratories. Qu-Resin covers a wide indication range thanks to its simple handling, quick setting, and life like color.
Dentist Use
Qu-Resin for intraoral use. The dentist is able to perform chair side repairs of the denture and reduce the amount of time considerably for both himself and the patient.
Laboratory Use
Compared to the conventional method of using cold-curing resin and polymerization in the pressure pot, Qu-Resin excels by reducing the processing time considerably. No pressure pot is required for Qu-Resin since the self-curing resin sets quickly.
Step 1
Tooth no. 24 is extracted and the partial denture is transformed into a full denture.
Step 2
A key is prepared to record the situation.
Step 3
The areas to be completed are roughened, Qu-Connector is applied and light-cured for 90 seconds. Then Qu-Resin is injected into the key; the key is replaced again and the tooth shape is completed from the oral direction.
Step 4
After curing, remove the key and complete the gingival sections of the denture with Qu-Resin.
